This class implements the Hilbert Schmidtd Independence Criterion based independence test as described in [1].
Given samples from the joint distribution , does the joint distribution factorize as ?
The HSIC is a kernel based independence criterion, which is based on the largest singular value of a CrossCovariance Operator in a reproducing kernel Hilbert space (RKHS). Its population expression is zero if and only if the two underlying distributions are independent.
This class can compute empirical biased estimates:
where is a centering matrix and are kernel matrices of both sets of samples.
Note that computing the statistic returns m*MMD; same holds for the null distribution samples.
Along with the statistic comes a method to compute a pvalue based on different methods. Bootstrapping, is also possible. If unsure which one to use, bootstrapping with 250 iterations always is correct (but slow).
To choose, use set_null_approximation_method() and choose from
HSIC_GAMMA: for a very fast, but not consistent test based on moment matching of a Gamma distribution, as described in [1].
BOOTSTRAPPING: For permuting available samples to sample nulldistribution. Bootstrapping is done on precomputed kernel matrices, since they have to be stored anyway when the statistic is computed.
A very basic method for kernel selection when using CGaussianKernel is to use the median distance of the underlying data. See examples how to do that. More advanced methods will follow in the near future. However, the median heuristic works in quite some cases. See [1].
[1]: Gretton, A., Fukumizu, K., Teo, C., & Song, L. (2008). A kernel statistical test of independence. Advances in Neural Information Processing Systems, 18.
Public Member Functions
CHSIC ()
CHSIC (CKernel *kernel_p, CKernel *kernel_q, CFeatures *p_and_q, index_t q_start)
CHSIC (CKernel *kernel_p, CKernel *kernel_q, CFeatures *p, CFeatures *q)
virtual  ~CHSIC ()
virtual float64_t  compute_statistic ()
virtual float64_t  compute_p_value (float64_t statistic)
virtual float64_t  compute_threshold (float64_t alpha)
virtual const char *  get_name () const
SGVector< float64_t >  fit_null_gamma ()
virtual SGVector< float64_t >  bootstrap_null ()
virtual void  set_bootstrap_iterations (index_t bootstrap_iterations)
virtual void  set_null_approximation_method (ENullApproximationMethod null_approximation_method)
virtual CSGObject *  shallow_copy () const
virtual CSGObject *  deep_copy () const
virtual bool  is_generic (EPrimitiveType *generic) const
template<class T >
void  set_generic ()
void  unset_generic ()
virtual void  print_serializable (const char *prefix="")
virtual bool  save_serializable (CSerializableFile *file, const char *prefix="", int32_t param_version=VERSION_PARAMETER)
virtual bool  load_serializable (CSerializableFile *file, const char *prefix="", int32_t param_version=VERSION_PARAMETER)
DynArray< TParameter * > *  load_file_parameters (const SGParamInfo *param_info, int32_t file_version, CSerializableFile *file, const char *prefix="")
DynArray< TParameter * > *  load_all_file_parameters (int32_t file_version, int32_t current_version, CSerializableFile *file, const char *prefix="")
void  map_parameters (DynArray< TParameter * > *param_base, int32_t &base_version, DynArray< const SGParamInfo * > *target_param_infos)
void  set_global_io (SGIO *io)
SGIO *  get_global_io ()
void  set_global_parallel (Parallel *parallel)
Parallel *  get_global_parallel ()
void  set_global_version (Version *version)
Version *  get_global_version ()
SGStringList< char >  get_modelsel_names ()
void  print_modsel_params ()
char *  get_modsel_param_descr (const char *param_name)
index_t  get_modsel_param_index (const char *param_name)
void  build_parameter_dictionary (CMap< TParameter *, CSGObject * > &dict)
Public Attributes
SGIO *  io
Parallel *  parallel
Version *  version
Parameter *  m_parameters
Parameter *  m_model_selection_parameters
ParameterMap *  m_parameter_map
uint32_t  m_hash
Protected Member Functions
SGMatrix< float64_t >  get_kernel_matrix_K ()
SGMatrix< float64_t >  get_kernel_matrix_L ()
virtual TParameter *  migrate (DynArray< TParameter * > *param_base, const SGParamInfo *target)
virtual void  one_to_one_migration_prepare (DynArray< TParameter * > *param_base, const SGParamInfo *target, TParameter *&replacement, TParameter *&to_migrate, char *old_name=NULL)
virtual void  load_serializable_pre () throw (ShogunException)
virtual void  load_serializable_post () throw (ShogunException)
virtual void  save_serializable_pre () throw (ShogunException)
virtual void  save_serializable_post () throw (ShogunException)
virtual bool  update_parameter_hash ()
Protected Attributes
CKernel *  m_kernel_p
CKernel *  m_kernel_q
CFeatures *  m_p_and_q
index_t  m_q_start
index_t  m_bootstrap_iterations
ENullApproximationMethod  m_null_approximation_method
Constructor
p_and_q  feature data. Is assumed to contain samples from both p and q. First all samples from p, then from index q_start all samples from q
kernel_p  kernel to use on samples from p
kernel_q  kernel to use on samples from q
p_and_q  samples from p and q, appended
q_start  index of first sample of q
Constructor. This is a convienience constructor which copies both features to one element and then calls the other constructor. Needs twice the memory for a short time
kernel_p  kernel to use on samples from p
kernel_q  kernel to use on samples from q
p  samples from distribution p, will be copied and NOT SG_REF'ed
q  samples from distribution q, will be copied and NOT SG_REF'ed
merges both sets of samples and computes the test statistic m_bootstrap_iteration times. This version precomputes the kenrel matrix once by hand, then performs bootstrapping on this one. The matrix has to be stored anyway when statistic is computed.
Reimplemented from CKernelIndependenceTestStatistic.

inherited
Builds a dictionary of all parameters in SGObject as well of those of SGObjects that are parameters of this object. Dictionary maps parameters to the objects that own them.
dict  dictionary of parameters to be built.
Definition at line 1204 of file SGObject.cpp.
computes a pvalue based on current method for approximating the nulldistribution. The pvalue is the 1p quantile of the null distribution where the given statistic lies in.
statistic  statistic value to compute the pvalue for
Reimplemented from CTwoDistributionsTestStatistic.

virtual
Computes the HSIC statistic (see class description) for underlying kernels and data. Note that it is multiplied by the number of used samples. It is a biased estimator. Note that it is m*HSIC_b.
Note that since kernel matrices have to be stored, it has quadratic space costs.
Implements CTestStatistic.
computes a threshold based on current method for approximating the nulldistribution. The threshold is the value that a statistic has to have in ordner to reject the nullhypothesis.
alpha  test level to reject nullhypothesis
Reimplemented from CTwoDistributionsTestStatistic.

virtualinherited
A deep copy. All the instance variables will also be copied.
Definition at line 131 of file SGObject.h.
Approximates the nulldistribution by a two parameter gamma distribution. Returns parameters.
NOTE: the gamma distribution is fitted to m*HSIC_b. But since compute_statistic() returnes the biased estimate, you can safely call this with values from compute_statistic(). However, the attached features have to be the SAME size, as these, the statistic was computed on. If compute_threshold() or compute_p_value() are used, this is ensured automatically. Note that m*Nulldistribution is fitted, which is fine since the statistic is also m*HSIC.
Has quadratic computational costs in terms of samples.
Called by compute_p_value() if null approximation method is set to MMD2_GAMMA.

inherited

inherited

inherited

inherited
Definition at line 1108 of file SGObject.cpp.

inherited
Returns description of a given parameter string, if it exists. SG_ERROR otherwise
param_name  name of the parameter
Definition at line 1132 of file SGObject.cpp.

inherited
Returns index of model selection parameter with provided index
param_name  name of model selection parameter
Definition at line 1145 of file SGObject.cpp.

virtual
Returns the name of the SGSerializable instance. It MUST BE the CLASS NAME without the prefixed `C'.
Implements CKernelIndependenceTestStatistic.

virtualinherited
If the SGSerializable is a class template then TRUE will be returned and GENERIC is set to the type of the generic.
generic  set to the type of the generic if returning TRUE
Definition at line 278 of file SGObject.cpp.

inherited
maps all parameters of this instance to the provided file version and loads all parameter data from the file into an array, which is sorted (basically calls load_file_parameter(...) for all parameters and puts all results into a sorted array)
file_version  parameter version of the file
current_version  version from which mapping begins (you want to use VERSION_PARAMETER for this in most cases)
file  file to load from
prefix  prefix for members
Definition at line 679 of file SGObject.cpp.

inherited
loads some specified parameters from a file with a specified version The provided parameter info has a version which is recursively mapped until the file parameter version is reached. Note that there may be possibly multiple parameters in the mapping, therefore, a set of TParameter instances is returned
param_info  information of parameter
file_version  parameter version of the file, must be <= provided parameter version
file  file to load from
prefix  prefix for members
Definition at line 523 of file SGObject.cpp.

virtualinherited
Load this object from file. If it will fail (returning FALSE) then this object will contain inconsistent data and should not be used!
file  where to load from
prefix  prefix for members
param_version  (optional) a parameter version different to (this is mainly for testing, better do not use)
Reimplemented in CModelSelectionParameters.
Definition at line 354 of file SGObject.cpp.

protectedvirtualinherited
Can (optionally) be overridden to postinitialize some member variables which are not PARAMETER::ADD'ed. Make sure that at first the overridden method BASE_CLASS::LOAD_SERIALIZABLE_POST is called.
ShogunException  Will be thrown if an error occurres.
Reimplemented in CKernel, CWeightedDegreePositionStringKernel, CList, CAlphabet, CLinearHMM, CGaussianKernel, CANOVAKernel, CInverseMultiQuadricKernel, CCircularKernel, and CExponentialKernel.
Definition at line 1033 of file SGObject.cpp.

protectedvirtualinherited
Can (optionally) be overridden to preinitialize some member variables which are not PARAMETER::ADD'ed. Make sure that at first the overridden method BASE_CLASS::LOAD_SERIALIZABLE_PRE is called.
ShogunException  Will be thrown if an error occurres.
Definition at line 1028 of file SGObject.cpp.

inherited
Takes a set of TParameter instances (base) with a certain version and a set of target parameter infos and recursively maps the base level wise to the current version using CSGObject::migrate(...). The base is replaced. After this call, the base version containing parameters should be of same version/type as the initial target parameter infos. Note for this to work, the migrate methods and all the internal parameter mappings have to match
param_base  set of TParameter instances that are mapped to the provided target parameter infos
base_version  version of the parameter base
target_param_infos  set of SGParamInfo instances that specify the target parameter base
Definition at line 717 of file SGObject.cpp.

protectedvirtualinherited
creates a new TParameter instance, which contains migrated data from the version that is provided. The provided parameter data base is used for migration, this base is a collection of all parameter data of the previous version. Migration is done FROM the data in param_base TO the provided param info Migration is always one version step. Method has to be implemented in subclasses, if no match is found, base method has to be called.
If there is an element in the param_base which equals the target, a copy of the element is returned. This represents the case when nothing has changed and therefore, the migrate method is not overloaded in a subclass
param_base  set of TParameter instances to use for migration
target  parameter info for the resulting TParameter
Definition at line 923 of file SGObject.cpp.

protectedvirtualinherited
This method prepares everything for a onetoone parameter migration. One to one here means that only ONE element of the parameter base is needed for the migration (the one with the same name as the target). Data is allocated for the target (in the type as provided in the target SGParamInfo), and a corresponding new TParameter instance is written to replacement. The to_migrate pointer points to the single needed TParameter instance needed for migration. If a name change happened, the old name may be specified by old_name. In addition, the m_delete_data flag of to_migrate is set to true. So if you want to migrate data, the only thing to do after this call is converting the data in the m_parameter fields. If unsure how to use  have a look into an example for this. (base_migration_type_conversion.cpp for example)
param_base  set of TParameter instances to use for migration
target  parameter info for the resulting TParameter
replacement  (used as output) here the TParameter instance which is returned by migration is created into
to_migrate  the only source that is used for migration
old_name  with this parameter, a name change may be specified
Definition at line 864 of file SGObject.cpp.

inherited
prints all parameter registered for model selection and their type
Definition at line 1084 of file SGObject.cpp.

virtualinherited
prints registered parameters out
prefix  prefix for members
Definition at line 290 of file SGObject.cpp.

virtualinherited
Save this object to file.
file  where to save the object; will be closed during returning if PREFIX is an empty string.
prefix  prefix for members
param_version  (optional) a parameter version different to (this is mainly for testing, better do not use)
Reimplemented in CModelSelectionParameters.
Definition at line 296 of file SGObject.cpp.

protectedvirtualinherited
Can (optionally) be overridden to postinitialize some member variables which are not PARAMETER::ADD'ed. Make sure that at first the overridden method BASE_CLASS::SAVE_SERIALIZABLE_POST is called.
ShogunException  Will be thrown if an error occurres.
Reimplemented in CKernel.
Definition at line 1043 of file SGObject.cpp.

protectedvirtualinherited
Can (optionally) be overridden to preinitialize some member variables which are not PARAMETER::ADD'ed. Make sure that at first the overridden method BASE_CLASS::SAVE_SERIALIZABLE_PRE is called.
ShogunException  Will be thrown if an error occurres.
Reimplemented in CKernel.
Definition at line 1038 of file SGObject.cpp.

virtualinherited
sets the number of bootstrap iterations for bootstrap_null()
bootstrap_iterations  how often bootstrapping shall be done
Definition at line 44 of file TestStatistic.cpp.

inherited
set generic type to T
Definition at line 41 of file SGObject.cpp.

inherited

inherited
set the parallel object
parallel  parallel object to use
Definition at line 230 of file SGObject.cpp.

inherited
set the version object
version  version object to use
Definition at line 265 of file SGObject.cpp.

virtualinherited
sets the method how to approximate the nulldistribution
null_approximation_method  method to use
Definition at line 38 of file TestStatistic.cpp.

virtualinherited
A shallow copy. All the SGObject instance variables will be simply assigned and SG_REFed.
Reimplemented in CGaussianKernel.
Definition at line 122 of file SGObject.h.

inherited
unset generic type
this has to be called in classes specializing a template class
Definition at line 285 of file SGObject.cpp.

protectedvirtualinherited
Updates the hash of current parameter combination.
Definition at line 237 of file SGObject.cpp.

inherited
io
Definition at line 462 of file SGObject.h.

protectedinherited
number of iterations for bootstrapping nulldistributions
Definition at line 98 of file TestStatistic.h.

inherited
Hash of parameter values
Definition at line 480 of file SGObject.h.

protectedinherited
underlying kernel for p
Definition at line 88 of file KernelIndependenceTestStatistic.h.

protectedinherited
underlying kernel for q
Definition at line 91 of file KernelIndependenceTestStatistic.h.

inherited
model selection parameters
Definition at line 474 of file SGObject.h.

protectedinherited
Defines how the the null distribution is approximated
Definition at line 101 of file TestStatistic.h.

protectedinherited
concatenated samples of the two distributions (two blocks)
Definition at line 94 of file TwoDistributionsTestStatistic.h.

inherited
map for different parameter versions
Definition at line 477 of file SGObject.h.

inherited
parameters
Definition at line 471 of file SGObject.h.

protectedinherited
defines the first index of samples of q
Definition at line 97 of file TwoDistributionsTestStatistic.h.

inherited
parallel
Definition at line 465 of file SGObject.h.

inherited
version
Definition at line 468 of file SGObject.h.
