SHOGUN
4.1.0
|
This class implements the CHAID algorithm proposed by Kass (1980) for decision tree learning. CHAID consists of three steps: merging, splitting and stopping. A tree is grown by repeatedly using these three steps on each node starting from the root node. CHAID accepts nominal or ordinal categorical predictors only. If predictors are continuous, they have to be transformed into ordinal predictors before tree growing.
CONVERTING CONTINUOUS PREDICTORS TO ORDINAL :
Continuous predictors are converted to ordinal by binning. The number of bins (K) has to be supplied by the user. Given K, a predictor is split in such a way that all the bins get the same number (more or less) of distinct predictor values. The maximum feature value in each bin is used as a breakpoint.
MERGING :
During the merging step, allowable pairs of categories of a predictor are evaluated for similarity. If the similarity of a pair is above a threshold, the categories constituting the pair are merged into a single category. The process is repeated until there is no pair left having high similarity between its categories. Similarity between categories is evaluated using the p_value
SPLITTING :
The splitting step selects which predictor to be used to best split the node. Selection is accomplished by comparing the adjusted p_value associated with each predictor. The predictor that has the smallest adjusted p_value is chosen for splitting the node.
STOPPING :
The tree growing process stops if any of the following conditions is satisfied :
.
在文件 CHAIDTree.h 第 90 行定义.
Public 类型 | |
| typedef CTreeMachineNode < CHAIDTreeNodeData > | node_t |
| typedef CBinaryTreeMachineNode < CHAIDTreeNodeData > | bnode_t |
Public 属性 | |
| SGIO * | io |
| Parallel * | parallel |
| Version * | version |
| Parameter * | m_parameters |
| Parameter * | m_model_selection_parameters |
| Parameter * | m_gradient_parameters |
| uint32_t | m_hash |
静态 Public 属性 | |
| static const float64_t | MISSING =CMath::MAX_REAL_NUMBER |
Protected 成员函数 | |
| virtual bool | train_machine (CFeatures *data=NULL) |
| virtual void | store_model_features () |
| virtual bool | train_require_labels () const |
| virtual void | load_serializable_pre () throw (ShogunException) |
| virtual void | load_serializable_post () throw (ShogunException) |
| virtual void | save_serializable_pre () throw (ShogunException) |
| virtual void | save_serializable_post () throw (ShogunException) |
Protected 属性 | |
| CTreeMachineNode < CHAIDTreeNodeData > * | m_root |
| CDynamicObjectArray * | m_machines |
| float64_t | m_max_train_time |
| CLabels * | m_labels |
| ESolverType | m_solver_type |
| bool | m_store_model_features |
| bool | m_data_locked |
|
inherited |
bnode_t type- Tree node with max 2 possible children
在文件 TreeMachine.h 第 55 行定义.
|
inherited |
node_t type- Tree node with many possible children
在文件 TreeMachine.h 第 52 行定义.
| CCHAIDTree | ( | ) |
default constructor
在文件 CHAIDTree.cpp 第 39 行定义.
| CCHAIDTree | ( | int32_t | dependent_vartype | ) |
constructor
| dependent_vartype | feature type for dependent variable (0-nominal, 1-ordinal or 2-continuous) |
在文件 CHAIDTree.cpp 第 45 行定义.
| CCHAIDTree | ( | int32_t | dependent_vartype, |
| SGVector< int32_t > | feature_types, | ||
| int32_t | num_breakpoints = 0 |
||
| ) |
constructor
| dependent_vartype | feature type for dependent variable (0-nominal, 1-ordinal or 2-continuous) |
| feature_types | type of various attributes (0-nominal, 1-ordinal or 2-continuous) |
| num_breakpoints | number of breakpoints for continuous to ordinal conversion of attributes |
在文件 CHAIDTree.cpp 第 52 行定义.
|
virtual |
destructor
在文件 CHAIDTree.cpp 第 61 行定义.
apply machine to data if data is not specified apply to the current features
| data | (test)data to be classified |
在文件 Machine.cpp 第 152 行定义.
|
virtualinherited |
apply machine to data in means of binary classification problem
被 CKernelMachine, COnlineLinearMachine, CWDSVMOcas, CNeuralNetwork, CLinearMachine, CGaussianProcessClassification, CDomainAdaptationSVMLinear, CDomainAdaptationSVM, CPluginEstimate , 以及 CBaggingMachine 重载.
在文件 Machine.cpp 第 208 行定义.
|
virtualinherited |
apply machine to data in means of latent problem
被 CLinearLatentMachine 重载.
在文件 Machine.cpp 第 232 行定义.
Applies a locked machine on a set of indices. Error if machine is not locked
| indices | index vector (of locked features) that is predicted |
在文件 Machine.cpp 第 187 行定义.
|
virtualinherited |
applies a locked machine on a set of indices for binary problems
被 CKernelMachine , 以及 CMultitaskLinearMachine 重载.
在文件 Machine.cpp 第 238 行定义.
|
virtualinherited |
applies a locked machine on a set of indices for latent problems
在文件 Machine.cpp 第 266 行定义.
|
virtualinherited |
applies a locked machine on a set of indices for multiclass problems
在文件 Machine.cpp 第 252 行定义.
|
virtualinherited |
applies a locked machine on a set of indices for regression problems
被 CKernelMachine 重载.
在文件 Machine.cpp 第 245 行定义.
|
virtualinherited |
applies a locked machine on a set of indices for structured problems
在文件 Machine.cpp 第 259 行定义.
|
virtual |
classify data using Classification Tree NOTE : This method replaces all values of continuous attributes in supplied data with the actual breakpoint values used for classification
| data | data to be classified |
重载 CMachine .
在文件 CHAIDTree.cpp 第 99 行定义.
|
virtualinherited |
applies to one vector
被 CKernelMachine, CRelaxedTree, CWDSVMOcas, COnlineLinearMachine, CLinearMachine, CMultitaskLinearMachine, CMulticlassMachine, CKNN, CDistanceMachine, CMultitaskLogisticRegression, CMultitaskLeastSquaresRegression, CScatterSVM, CGaussianNaiveBayes, CPluginEstimate , 以及 CFeatureBlockLogisticRegression 重载.
|
virtual |
Get regression labels using Regression Tree NOTE : This method replaces all values of continuous attributes in supplied data with the actual breakpoint values used for classification
| data | data whose regression output is needed |
重载 CMachine .
在文件 CHAIDTree.cpp 第 106 行定义.
|
virtualinherited |
apply machine to data in means of SO classification problem
被 CLinearStructuredOutputMachine 重载.
在文件 Machine.cpp 第 226 行定义.
|
inherited |
Builds a dictionary of all parameters in SGObject as well of those of SGObjects that are parameters of this object. Dictionary maps parameters to the objects that own them.
| dict | dictionary of parameters to be built. |
在文件 SGObject.cpp 第 597 行定义.
| void clear_feature_types | ( | ) |
clear feature types of various features
在文件 CHAIDTree.cpp 第 143 行定义.
| void clear_weights | ( | ) |
clear weights of data points
在文件 CHAIDTree.cpp 第 127 行定义.
|
virtualinherited |
Creates a clone of the current object. This is done via recursively traversing all parameters, which corresponds to a deep copy. Calling equals on the cloned object always returns true although none of the memory of both objects overlaps.
在文件 SGObject.cpp 第 714 行定义.
|
inherited |
Locks the machine on given labels and data. After this call, only train_locked and apply_locked may be called
Only possible if supports_locking() returns true
| labs | labels used for locking |
| features | features used for locking |
被 CKernelMachine 重载.
在文件 Machine.cpp 第 112 行定义.
|
virtualinherited |
Unlocks a locked machine and restores previous state
被 CKernelMachine 重载.
在文件 Machine.cpp 第 143 行定义.
|
virtualinherited |
A deep copy. All the instance variables will also be copied.
在文件 SGObject.cpp 第 198 行定义.
Recursively compares the current SGObject to another one. Compares all registered numerical parameters, recursion upon complex (SGObject) parameters. Does not compare pointers!
May be overwritten but please do with care! Should not be necessary in most cases.
| other | object to compare with |
| accuracy | accuracy to use for comparison (optional) |
| tolerant | allows linient check on float equality (within accuracy) |
在文件 SGObject.cpp 第 618 行定义.
| float64_t get_alpha_merge | ( | ) | const |
| float64_t get_alpha_split | ( | ) | const |
|
virtualinherited |
get classifier type
被 CLaRank, CSVMLight, CDualLibQPBMSOSVM, CNeuralNetwork, CCCSOSVM, CLeastAngleRegression, CLDA, CKernelRidgeRegression, CLibLinearMTL, CBaggingMachine, CLibLinear, CGaussianProcessClassification, CKMeans, CLibSVR, CQDA, CGaussianNaiveBayes, CSVRLight, CMCLDA, CLinearRidgeRegression, CKNN, CScatterSVM, CGaussianProcessRegression, CSGDQN, CSVMSGD, CSVMOcas, COnlineSVMSGD, CLeastSquaresRegression, CMKLRegression, CDomainAdaptationSVMLinear, CMKLMulticlass, CWDSVMOcas, CHierarchical, CMKLOneClass, CLibSVM, CStochasticSOSVM, CMKLClassification, CDomainAdaptationSVM, CLPBoost, CPerceptron, CAveragedPerceptron, CFWSOSVM, CNewtonSVM, CLPM, CGMNPSVM, CSVMLightOneClass, CSVMLin, CMulticlassLibSVM, CLibSVMOneClass, CMPDSVM, CGPBTSVM, CGNPPSVM , 以及 CCPLEXSVM 重载.
在文件 Machine.cpp 第 92 行定义.
| int32_t get_dependent_vartype | ( | ) | const |
get dependent variable type : 0 for nominal, 1 for ordinal and 2 for continuous
在文件 CHAIDTree.h 第 177 行定义.
| SGVector< int32_t > get_feature_types | ( | ) | const |
get feature types of various features
在文件 CHAIDTree.cpp 第 138 行定义.
|
inherited |
|
inherited |
|
inherited |
|
virtualinherited |
|
virtual |
get problem type - multiclass classification or regression
在文件 CHAIDTree.cpp 第 65 行定义.
|
inherited |
| int32_t get_min_node_size | ( | ) | const |
|
inherited |
在文件 SGObject.cpp 第 498 行定义.
|
inherited |
Returns description of a given parameter string, if it exists. SG_ERROR otherwise
| param_name | name of the parameter |
在文件 SGObject.cpp 第 522 行定义.
|
inherited |
Returns index of model selection parameter with provided index
| param_name | name of model selection parameter |
在文件 SGObject.cpp 第 535 行定义.
|
virtual |
| float64_t get_num_breakpoints | ( | ) | const |
|
inherited |
|
inherited |
|
inherited |
| int32_t get_specified_max_tree_depth | ( | ) | const |
|
virtualinherited |
If the SGSerializable is a class template then TRUE will be returned and GENERIC is set to the type of the generic.
| generic | set to the type of the generic if returning TRUE |
在文件 SGObject.cpp 第 296 行定义.
|
virtual |
whether labels supplied are valid for current problem type
| lab | labels supplied |
在文件 CHAIDTree.cpp 第 82 行定义.
|
virtualinherited |
Load this object from file. If it will fail (returning FALSE) then this object will contain inconsistent data and should not be used!
| file | where to load from |
| prefix | prefix for members |
在文件 SGObject.cpp 第 369 行定义.
|
protectedvirtualinherited | |||||||||||||
Can (optionally) be overridden to post-initialize some member variables which are not PARAMETER::ADD'ed. Make sure that at first the overridden method BASE_CLASS::LOAD_SERIALIZABLE_POST is called.
| ShogunException | will be thrown if an error occurs. |
被 CKernel, CWeightedDegreePositionStringKernel, CList, CAlphabet, CLinearHMM, CGaussianKernel, CInverseMultiQuadricKernel, CCircularKernel , 以及 CExponentialKernel 重载.
在文件 SGObject.cpp 第 426 行定义.
|
protectedvirtualinherited | |||||||||||||
Can (optionally) be overridden to pre-initialize some member variables which are not PARAMETER::ADD'ed. Make sure that at first the overridden method BASE_CLASS::LOAD_SERIALIZABLE_PRE is called.
| ShogunException | will be thrown if an error occurs. |
被 CDynamicArray< T >, CDynamicArray< float64_t >, CDynamicArray< float32_t >, CDynamicArray< int32_t >, CDynamicArray< char >, CDynamicArray< bool > , 以及 CDynamicObjectArray 重载.
在文件 SGObject.cpp 第 421 行定义.
|
virtualinherited |
在文件 SGObject.cpp 第 262 行定义.
|
inherited |
prints all parameter registered for model selection and their type
在文件 SGObject.cpp 第 474 行定义.
|
virtualinherited |
|
virtualinherited |
Save this object to file.
| file | where to save the object; will be closed during returning if PREFIX is an empty string. |
| prefix | prefix for members |
在文件 SGObject.cpp 第 314 行定义.
|
protectedvirtualinherited | |||||||||||||
Can (optionally) be overridden to post-initialize some member variables which are not PARAMETER::ADD'ed. Make sure that at first the overridden method BASE_CLASS::SAVE_SERIALIZABLE_POST is called.
| ShogunException | will be thrown if an error occurs. |
被 CKernel 重载.
在文件 SGObject.cpp 第 436 行定义.
|
protectedvirtualinherited | |||||||||||||
Can (optionally) be overridden to pre-initialize some member variables which are not PARAMETER::ADD'ed. Make sure that at first the overridden method BASE_CLASS::SAVE_SERIALIZABLE_PRE is called.
| ShogunException | will be thrown if an error occurs. |
被 CKernel, CDynamicArray< T >, CDynamicArray< float64_t >, CDynamicArray< float32_t >, CDynamicArray< int32_t >, CDynamicArray< char >, CDynamicArray< bool > , 以及 CDynamicObjectArray 重载.
在文件 SGObject.cpp 第 431 行定义.
| void set_alpha_merge | ( | float64_t | a | ) |
| void set_alpha_split | ( | float64_t | a | ) |
| void set_dependent_vartype | ( | int32_t | var | ) |
set dependent variable type : 0 for nominal, 1 for ordinal and 2 for continuous
| var | integer corresponding to the dependent variable type |
在文件 CHAIDTree.cpp 第 148 行定义.
| void set_feature_types | ( | SGVector< int32_t > | ft | ) |
set feature types of various features
| ft | vector with feature types : 0-nominal, 1-ordinal or 2-continuous |
在文件 CHAIDTree.cpp 第 133 行定义.
|
inherited |
在文件 SGObject.cpp 第 41 行定义.
|
inherited |
在文件 SGObject.cpp 第 46 行定义.
|
inherited |
在文件 SGObject.cpp 第 51 行定义.
|
inherited |
在文件 SGObject.cpp 第 56 行定义.
|
inherited |
在文件 SGObject.cpp 第 61 行定义.
|
inherited |
在文件 SGObject.cpp 第 66 行定义.
|
inherited |
在文件 SGObject.cpp 第 71 行定义.
|
inherited |
在文件 SGObject.cpp 第 76 行定义.
|
inherited |
在文件 SGObject.cpp 第 81 行定义.
|
inherited |
在文件 SGObject.cpp 第 86 行定义.
|
inherited |
在文件 SGObject.cpp 第 91 行定义.
|
inherited |
在文件 SGObject.cpp 第 96 行定义.
|
inherited |
在文件 SGObject.cpp 第 101 行定义.
|
inherited |
在文件 SGObject.cpp 第 106 行定义.
|
inherited |
在文件 SGObject.cpp 第 111 行定义.
|
inherited |
set generic type to T
|
inherited |
|
inherited |
|
inherited |
|
virtualinherited |
set labels
| lab | labels |
被 CNeuralNetwork, CGaussianProcessMachine, CCARTree, CStructuredOutputMachine, CRelaxedTree , 以及 CMulticlassMachine 重载.
在文件 Machine.cpp 第 65 行定义.
|
inherited |
| void set_max_tree_depth | ( | int32_t | d | ) |
| void set_min_node_size | ( | int32_t | size | ) |
| void set_num_breakpoints | ( | int32_t | b | ) |
|
inherited |
|
inherited |
|
virtualinherited |
Setter for store-model-features-after-training flag
| store_model | whether model should be stored after training |
在文件 Machine.cpp 第 107 行定义.
|
virtualinherited |
A shallow copy. All the SGObject instance variables will be simply assigned and SG_REF-ed.
被 CGaussianKernel 重载.
在文件 SGObject.cpp 第 192 行定义.
|
protectedvirtualinherited |
enable unlocked cross-validation - no model features to store
重载 CMachine .
在文件 TreeMachine.h 第 152 行定义.
|
virtualinherited |
被 CKernelMachine , 以及 CMultitaskLinearMachine 重载.
|
virtualinherited |
train machine
| data | training data (parameter can be avoided if distance or kernel-based classifiers are used and distance/kernels are initialized with train data). If flag is set, model features will be stored after training. |
被 CRelaxedTree, CAutoencoder, CSGDQN , 以及 COnlineSVMSGD 重载.
在文件 Machine.cpp 第 39 行定义.
Trains a locked machine on a set of indices. Error if machine is not locked
NOT IMPLEMENTED
| indices | index vector (of locked features) that is used for training |
被 CKernelMachine , 以及 CMultitaskLinearMachine 重载.
|
protectedvirtual |
train machine - build CHAID from training data
| data | training data |
重载 CMachine .
在文件 CHAIDTree.cpp 第 154 行定义.
|
protectedvirtualinherited |
returns whether machine require labels for training
被 COnlineLinearMachine, CHierarchical, CLinearLatentMachine, CVwConditionalProbabilityTree, CConditionalProbabilityTree , 以及 CLibSVMOneClass 重载.
|
inherited |
unset generic type
this has to be called in classes specializing a template class
在文件 SGObject.cpp 第 303 行定义.
|
virtualinherited |
Updates the hash of current parameter combination
在文件 SGObject.cpp 第 248 行定义.
|
inherited |
io
在文件 SGObject.h 第 369 行定义.
|
inherited |
parameters wrt which we can compute gradients
在文件 SGObject.h 第 384 行定义.
|
inherited |
Hash of parameter values
在文件 SGObject.h 第 387 行定义.
|
protectedinherited |
machines
在文件 BaseMulticlassMachine.h 第 56 行定义.
|
inherited |
model selection parameters
在文件 SGObject.h 第 381 行定义.
|
inherited |
parameters
在文件 SGObject.h 第 378 行定义.
|
protectedinherited |
tree root
在文件 TreeMachine.h 第 156 行定义.
|
protectedinherited |
|
protectedinherited |
|
static |
denotes that a feature in a vector is missing MISSING = MAX_REAL_NUMBER
在文件 CHAIDTree.h 第 393 行定义.
|
inherited |
parallel
在文件 SGObject.h 第 372 行定义.
|
inherited |
version
在文件 SGObject.h 第 375 行定义.
